Highest specifications, 2K image quality, fully waterproof
AD2S DRIVING VIDEO RECODER
  • Sony IMX335 sensor
  • The whole machine is waterproof / the host is IP66 waterproof; the lens is IP67 waterproof and dustproof
  • Explosion-proof and durable supercapacitor
  • Maximum image resolution Quad HD 2560P 2560 X 1440
  • Separate lens 6G+IR filter; 140-degree high wide angle F1.8 large aperture
  • Multifunctional wired controller, exclusively integrated with GPS, radio, gear lock, and status indicator light
  • G-Sensor gravity sensing lock, automatically and forcefully save accident images
  • Seamless loop recording, video connection without missing a second; start recording when the vehicle is on, and shut down when the vehicle is powered off
  • Supports up to 256GB memory card
US 262.18
  • G-SENSOR
    G-SENSOR
  • Aperture F1.8
    Aperture F1.8
  • Super Wide 140°
    Super Wide 140°
  • Controller
    Controller
  • IP67
    IP67
  • OTG
    OTG
  • SONY CMOS
    SONY CMOS
  • HD 720p
    HD 720p
  • BSMI certification
    BSMI certification
  • Replay accident dissension
    Replay accident dissension
  • GPS定位
    GPS定位
  • WIFI
    WIFI
  • Audio input High sensitivity microphone built in external controller
    Audio input High sensitivity microphone built in external controller
  • Supercapacitor
    Supercapacitor
  • Novatek
    Novatek
  • Built-in WiFi module with exclusive AmberCam app available for iOS Android system
    Built-in WiFi module with exclusive AmberCam app available for iOS Android system
  • WDR
    WDR
  • TS碼流
    TS碼流


  • Battery
    Explosion-proof durable super capacitor
  • Explosion-proof durable super capacitor gravity sensor
    Built-in G-Sensor sensing lock
  • Video Resolution
    Quad HD 2560P 2560x1440 30fps
  • Waterproof Specifications
    Lens IP67/Host IP66
  • Power supply method
    Input 12V
  • Storage space
    Maximum support for 256GB MicroSD™ memory card
  • Voice input
    Multifunctional external high-sensitivity microphone for independent sound collection
  • Locking function
    Multifunctional external independent controller manual locking
  • GPS module
    Multifunctional external independent controller with built-in GPS and supports GPS positioning
  • Mobile device connection
    Built-in WiFi module, exclusive to Amber Cam App supports iOS/Android system
  • Loop recording
    1/3/5 minutes loop recording
  • USB specification
    USB 2.0
  • Video format
    TS stream
  • Display screen
    Fully fitted 3-inch IPS screen, resolution 720P
  • Lens
    140-degree ultra-wide-angle 6-layer all-glass lens
  • Photosensitive element
    SONY IMX335 CMOS
  • Aperture
    F1.8 large aperture
  • Body size (WxHxD)
    102x63.4x24.6mm
  • Working temperature
    The maximum heat resistance is 70 degrees Celsius
  • AD2S_蝦皮2
    AD2S_蝦皮2
Manual
  • date
    2023-11-01
    description
    AD2S manual (back)
  • date
    2023-11-01
    description
    AD2S manual (front)
